DFS60B-S4EL01000 انکودر افزایشی با کد فنی 1037285 کابل 3 متری

DFS60B-S4EL01000 انکودر افزایشی

• DFS60B-S4EL01000 انکودر افزایشی: Pulses per revolution 1,000 1) Measuring step 90°, electric/pulses per revol... Measuring step deviation at non binary number of lines ± 0.01° Error limits ± 0.05° 1) See maximum revolution range. Interfaces Communication interface Incremental Communication Interface detail HTL / Push pull Number of signal channels 6-channel Initialization time 40 ms Output frequency ≤ 600 kHz Load current ≤ 30 mA Power consumption ≤ 0.5 W (without load) Electronics Connection type Cable, 8-wire, universal, 3 m 1) Supply voltage 10 ... 32 V Reference signal, number 1 Reference signal, position 90°, electric, log... Reverse polarity protection ✔ 1) The universal cable connection is positioned so... 2) Short-circuit opposite to another channel, US o... 2 INCREMENTAL ENCODERS | SICK Data sheet | 2025-12... Subject to change without notice DFS60B-S4EL01000 | DFS60 INCREMENTAL ENCODERS Short-circuit protection of the outputs ✔ 2) 1) The universal cable connection is positioned so... 2) Short-circuit opposite to another channel, US o... Mechanics Mechanical design Solid shaft, face mount flange Shaft diameter 10 mm With flat Shaft length 19 mm Weight + 0.3 kg Shaft material Stainless steel Flange material Aluminum Housing material Aluminum die cast Start up torque 0.5 Ncm (+20 °C) Operating torque 0.3 Ncm (+20 °C) Permissible shaft loading 80 N (radial) 40 N (axial) Operating speed ≤ 9,000 min⁻¹ 1) Moment of inertia of the rotor 6.2 gcm² Bearing lifetime 3.6 x 10^10 revolutions Angular acceleration ≤ 500,000 rad/s²
